XeRun XR10 Justock
XeRun XR10 Justock
Regular price
$109.95 AUD
Regular price
Sale price
$109.95 AUD
Unit price
per
Tax included.
Couldn't load pickup availability
Description
Zero-timing Design
The XR10 JUSTOCK ESC is specifically designed
for Zero-timing racing class. Its timing system has
been permanently set to ZERO degree. Using the
same branded motor and winding will ensure that
every racer will have the same power system for
100% fair and competitive racing.
High Reliability & Durability
Reliable hardware combined with advanced software
technology allows the XR10 JUSTOCK to not only
provide high power output, but also overload
protection of the ESC circuit.
High efficient Heat
Dissipating System
The modified heatsink, which increases the
surface area, combined with the HOBBYWING
patented copper heat-conductive plates which
are attached to the MOSFET board allows the
internal heat to be quickly transferred to the
heatsink for dissipation. With the
high-performing detachable cooling fan, a
highly reliable heat transfer system for
maximum cooling is accomplished.
Product Name
XeRun XR10 Justock
Product Number
30112000
Type
Scale
1/10th
Brushed/Brushless
BL
Sensored/Sensorless
SD
Waterproof
No
Specifications
Cont./Peak Current
60A/380A
Input
2-3S LiPo/6-9 Cells NiMH
BEC Output
6V@2A
Wires & Connectors
Input Wires
Red-14AWG-200mm*1/Black-14AWG-200mm*1
Output Wires
Blue-14AWG-200mm*1/Yellow-14AWG-200mm*1/Orange-14AWG-200mm*1
Input Connectors
No
Output Connecotors
No
(Note: All the wire length above is the original length not the length you see from the outside.)
Fan
Size
25x25x10mm
Voltage Range
5-8.4V
Powered by
Powered by BEC
ESC Programing via
SET Button on ESC
Supported
LED Program Box
Supported
LCD Program Box
Supported
WiFi Module
Supported
Programming Wire
Programming/Throttle Wire
Firmware
Firmware Upgrade
Supported
Size & Weight
Size
33.5x28.5x30.5mm
Weight
59.8g
Applications
Motors
SL BL Motors
SD BL Motors
Vehicles
1/10th,1/12thTouring Car/Buggy Competitions (Especially Stock Class)
KV Rating/T Count
2S LiPo: 1/10th Touring Cars≥8.5T, 1/10th Buggies≥11.5T
3S LiPo: 1/10th Touring Cars≥13.5T, 1/10th Buggies≥17.5T
3650 Motors
***There is a 3 to 5 day turnaround time on all hobbywing items
